Backyard workspace checklist: survey, panel and delivery route
A homeowner checklist for a backyard workspace: the survey, the panel capacity check and the delivery route, who does each one and what each can cancel.
What to take away
- Three checks get dropped more than any othersthe survey, the panel capacity check and the delivery route.
- Each one can cancel the project as designed, so do all three before a deposit is paid.
- Learning the answer in week two beats learning it in month four, so run the checks in order.
- Nothing here replaces your local building department's answer.
Why these three come before design money
Each of these checks can end the project as designed, and each is cheap before the foundation and expensive after it. They come before design money because their answers change the footprint, the electrical scope and the way the shell reaches the site.
The order matters. The survey fixes where the studio can sit, the panel check fixes what it can power, and the delivery route fixes how the shell arrives. A failure in the first can make the other two irrelevant.
Check one: the survey, not the fence
Stake the footprint at full size and check it against the survey, not the fence. Fences are unreliable, and a setback error cannot be fixed once concrete is poured. On a constrained lot, a survey is worth having before any design is drawn.
- Pull the survey and mark the setbacks and easements on a working copy.
- Stake the footprint at full size on the ground.
- Measure from the stakes to the survey lines, never to the fence.
- Move the stakes, not the survey, when the numbers do not fit.
Utility marks belong in the same visit. The Pipeline and Hazardous Materials Safety Administration explains that a call to 811 lets operators locate and mark underground facilities for a homeowner or a professional excavator, and that the call is free. Note the septic field, well, sewer line and water service on the plan too.
Check two: the electrical panel
Check the electrical panel for spare capacity and note the distance from the panel to the studio. Skipping this leads to a service upgrade discovered halfway through the job, which is the worst moment to learn it.
Spare capacity is not the same as empty slots in the panel, because a panel can have free spaces and still be too small for the new load. That is why the last item below goes to a professional.
- Read the amp rating on the main breaker
- Count the open breaker spaces
- Measure the run from the panel to the studio
- Ask a licensed electrician for a load calculation under the National Electrical Code (NFPA 70), which covers service and feeder calculations in Article 220
Decide the electrical scope now, together with the foundation, not later. Conduit run for anything future is cheap at this stage and disruptive afterwards. The power and siting lessons from finished projects show how often the panel decides the layout.
Check three: the delivery route
Confirm the turning space, the crane position and who carries the access risk, in writing, before any deposit is paid. Skipping this leads to a module that cannot reach the site, and the deposit on it is usually gone.
- Get the module dimensions and weight from the supplier in writing
- Walk the route from the road to the pad and measure gates, overhead lines, branches, slopes and corners
- Mark where the truck and the crane will stand
- Agree who carries the access risk, in writing
Ask every bidder for the written scope, with exclusions, and make delivery and access part of it. Confirm lead times for windows, doors and heating equipment at the same time, because a late delivery date can matter as much as a blocked one.
Site rules that decide whether the design is allowed
Confirm setbacks, height limit, lot coverage and permitted floor area at your address. Then check deed restrictions, easements and association rules separately from the city, because the city's answer does not cover the deed.
Before You Design
- Confirm setbacks, height limit, lot coverage
- Ask if use changes classification
- Check deed restrictions, easements, association rules
- Locate septic, well, sewer, water, utilities
- Check electrical panel spare capacity
- Write one page briefhours, people, equipment
File the building permit application with your local building department, and ask which code edition applies. Most US jurisdictions adopt the International Residential Code (IRC) for a one-family building like this, with state and local amendments.
The International Residential Code is the ICC's model code for one- and two-family dwellings and townhouses. Ask whether your intended use changes the classification of the building.
Write the one-page brief
Write a one-page brief: hours, people, equipment, storage, and the noise made and tolerated. The brief turns the three checks into questions with answers, such as how much power the room needs and how much floor it must hold.
Run the brief beside the design decisions and the budget layers, so that a checked item is also a priced item.
What the checks hand over to the pour
Once the three checks pass, the same facts feed the pre-pour setup. The survey gives the layout something to be checked against, and the locate marks show where the trench and footing must not go. Confirm these before the concrete arrives:
- Building permit issued and posted, with the drawings on site.
- Foundation layout checked against the drawings and the property line.
- Drainage plan agreed, including where the downspouts discharge.
- Inspection booked, with a fallback date.
A pour is the first step that cannot be quietly undone, so a missing item here is a reason to wait a day rather than a reason to pour and hope. Walk the stakes, the marks and the drawings together on the morning of the pour.
Who does each check, and what it can cancel
| Check | Who does it | What it can cancel |
|---|---|---|
| Survey | You, staking against the survey lines | A footprint that breaks a setback |
| Panel | A licensed electrician, with your measurements | A layout that needs a service upgrade |
| Delivery route | You and the supplier, in writing | A module that cannot reach the site |
| Utility locate | Facility operators, after your call to 811 | A foundation over a buried line |
Do them in this order, because each can cancel the project as designed. Print the table, mark a date against each line, and keep it with the permit.
